Our signature luminaire

Designed for high ingress protection, easy maintenance and award-winning optical performance, the Windsor luminaire features latest generation technology whilst preserving the elegance of the original.

  • Choice of three styles - Boulevard, Avenue or Street
  • Recommended for mounting at 3-6 metres
  • Available with a range of LED light sources to suit both performance and comfort applications

Request a quote

Product Selector

Weight (kg)

Choose

Windage (m2)

Choose

Products in this range

(3 in total)

Change view:

Product

Windsor Street

Product

Windsor Avenue

Product

Windsor Boulevard
Name Weight (kg) Windage (m2)
Windsor Street 10.3 0.28
Windsor Avenue 8.3 0.22
Windsor Boulevard 12.3 0.34
Contact us about this product
10.3
0.28
8.3
0.22
12.3
0.34

Windsor



Copper construction

For more than 40 years, we have been handcrafting an extensive range of heritage lanterns from copper.  As well as being naturally attractive, copper is a tough and corrosion resistant material offering incredible longevity.

Mounting options

Windsor Avenue, Windsor Street and Windsor Boulevard are supplied with a Ø76mm frog mounting as standard.  Windsor Street is available with an optional cast base.

Suggested column / bracket options

See the column and bracket section for our full range of decorative columns and wall brackets.

See our columns

Installation and maintenance

Frog and cast bases have external connector blocks for ease of installation. Tool-less maintenance via hinged, sealed canopy with retaining stay and slide latches.

LED Light engines

Designed to fit effortlessly within the majority of our exterior lighting luminaires, the LED Light Engine is available in new luminaires or as a retrofit option.

Performance LED

For optimised energy savings and lighting performance featuring Diamond+.

Performance CoB

For performance lighting with the appearance of a lamp.

Comfort CoB

For energy savings and pedestrian friendly lighting.

Braun, by DW Windsor

For the ultimate authentic heritage aesthetic.

Standard colours

RAL 9005 Fine textured black colour swatch 548x548px

RAL 9005

Black

RAL 7016 Anthracite grey colour swatch 548x548px

RAL 7016

Anthracite grey

RAL 7037 Dusty grey colour swatch 548x548px

RAL 7037

Dusty grey

RAL 5003 Sapphire blue colour swatch 548x548px

RAL 5003

Sapphire blue

RAL 6005 Light moss green colour swatch 548x548px

RAL 6005

Light moss green

RAL 3005 Wine red colour swatch 548x548px

RAL 3005

Wine red

To personalise your scheme, other RAL colours available on request.

Detailed Specification

Product specification

Electrical Class:
I (II on request)
IK rating:
IK08
Mounting Height (m):
03-Jun
Applications:
Public realm
High street & road lighting
Paths & walkways
Rail
Car parks

Lighting

Lumen Range (lumens):
1083-9930
LED qty:
1-64

Mechanical and installation

Materials:
Body: Copper
Glazing: Clear polycarbonate
Seals: Silicone
Finish:
Natural copper
Polished and lacquered copper
Polyester powder coat

Downloads and dimensions

Retrofit LED Solutions brochure

Format: Adobe Acrobat PDF file, (1.8 MB)

Download

Light Engine Design Guide

Format: Adobe Acrobat PDF file, (6.6 MB)

Download

Windsor product codes

Format: Adobe Acrobat PDF file, (36 KB)

Download

Windsor installation instructions

Format: Adobe Acrobat PDF file, (517 KB)

Download

Windsor Avenue photometry

Format: ZIP compressed file, (4.9 MB)

Download

Windsor Boulevard photometry

Format: ZIP compressed file, (11 MB)

Download

Windsor Street photometry

Format: ZIP compressed file, (4.7 MB)

Download
Windsor Street product dimension drawing W573px
Dimensions (mm):
  • A 1005
  • Ø B 495
  • Ø C 76
  • D 188
Weight (kg):
12.3
Windage (m2):
0.34
Windsor Street product dimension drawing W573px
Dimensions (mm):
  • A 833
  • Ø B 440
  • Ø C 76
  • D 188
Weight (kg):
10.3
Windage (m2):
0.28
Windsor Avenue product dimension drawing W573px
Dimensions (mm):
  • A 745
  • Ø B 390
  • Ø C 76
  • D 115
Weight (kg):
8.3
Windage (m2):
0.22
Dimensions (mm):
  • A 825
  • Ø B 417
  • Ø C 76
  • D 115
Weight (kg):
7.9
Windage (m2):
0.28
