This product is now discontinued.
Please find all information about Katana in the downloads section of this page.
If you have any questions, please get in touch.
Contact us
Get in touch
Detailed Specification
Product specification
Electrical Class:
I (II on request)
IP rating:
IP66
IK rating:
IK10
Certifications:
UKCA, CE
Mounting Height (m):
5-10
Applications:
Public realm
High street & road lighting
High street & road lighting
Lighting
Light source:
Mid power LED
Optical control (lookup):
Diamond+
Lumen Range (lumens):
600-16100
Power Range:
31 - 134 lm
LED qty:
16
Distribution:
5 Diamond+ Optics (A / B / C / D)
Colour Temperature (CCT):
2700K
3000K
4000K
3000K
4000K
Colour rendering (CRI):
>70Ra (4000K)
>80Ra (3000K / 27000K)
>80Ra (3000K / 27000K)
Max efficacy (luminaire lumens):
up to 140lm/W
L90 Lifetime Estimate:
>100,000hrs
Power and control
Voltage:
220 - 240V
Drive Current Range:
75mA-800mA (in 25mA increments)
Controls:
Photocell
Part night switching
Pre-programmed dimming
Integral CMS
Part night switching
Pre-programmed dimming
Integral CMS
Surge protection:
10kV
Driver:
Philips Xi
Mechanical and installation
Materials:
Body & entries: High pressure die-cast aluminium
Outer surfaces: Aluminium
Seals: Silicone
Glazing: Toughened glass for IK09 / Polycarbonate for IK10
Outer surfaces: Aluminium
Seals: Silicone
Glazing: Toughened glass for IK09 / Polycarbonate for IK10
Finish:
Polyester powder coat
Product colours:
RAL 9016 White
RAL 9005 Black
RAL 9006 Aluminium
RAL 9007 Metallic grey
DB 703 Metallic dark grey
Corten brown
Other RAL colours on request
RAL 9005 Black
RAL 9006 Aluminium
RAL 9007 Metallic grey
DB 703 Metallic dark grey
Corten brown
Other RAL colours on request
Operating temp (°C):
-25°C to +50°C
Mounting:
Catenary Hanger
Dimensions
Dimensions (mm):
- A 650
- B 105
Weight (kg):
14.25
14.25
Windage (m2):
0.076
0.076
Dimensions (mm):
- A 779
- B 105
Weight (kg):
14.7
14.7
Windage (m2):
0.079
0.079
