Award-winning handrail lighting for internal and external applications
Best-on-market performance and uniformity
Our award-winning recessed lighting solution for retrofit into handrail applications. Three standard module options offer a wide range of lighting levels, colour temperatures and distributions.
- Suitable for exterior and interior use
- Range of colour temperatures to suit project requirements
- Precise lighting control, for where light is needed
- 3 standard modules available: Garda, Garda Pro and Garda Comfort
- Exclusive to international specifications
Contact us
Contact us
Product Selector
Lumen Range (lumens)204-1956
Download photometry
Please enter email address to download photometry
Garda InRail
Offering symmetric and asymmetric performance for a large range of handrail applications. At launch, Garda set the standard for handrail lighting.
| Symmetric module | Asymmetric module | |||||
| Length (mm) | 2700K | 3000K | 4000K | 2700K | 3000K | 4000K |
| 300mm | 201lm | 281lm | 335lm | 146lm | 204lm | 244lm |
| 600mm | 402lm | 563lm | 670lm | 293lm | 410lm | 489lm |
Garda InRail Pro
Garda InRail Pro is our NEW performance handrail solution with asymmetric distribution. Designed for schemes which require increased module spacings, or high (150lux+) lighting levels and uniformity. For optimised lighting, performance and cost.
| Asymmetric module |
||
| Length (mm) | 3000K | 4000K |
| 300mm | 449lm | 489lm |
| 600mm | 894lm | 972lm |
Garda InRail Comfort
Ensuring we have a solution for every project need; NEW Garda InRail Comfort is now available. With no visible LEDs, it offers a comfortable homogenous light. Its lower lighting levels - of 30lux - provide efficient lighting performance.
| Symmetric module | |||
| Length (mm) | 2700K | 3000K | 4000K |
| 300mm | 294lm | 300lm | 320lm |
| 600mm | 647lm | 654lm | 703lm |
Full control and conformity
Control
- Total lighting control offered with switching and dimming options, and building management system integration via DALI
- Integrated emergency 3-hour functionality, including DALI self-test
Protection
- Class III
- IP66
- Electrical integrity maintained with IP66 rated cables and transformer enclosures
- Surge protected
Manufactured in a quality assured environment
- ISO 9001 - Quality Management
- ISO 14001 - Environmental Management
- OHSAS 18001 - Occupational Health and Safety Management
Compliance
- Lighting levels designed to customer specification or to meet British Standard (BS 5489-1:2013)
