Cannon

Change view:

More Views

With cast iron body and polycarbonate glazing for superior durability, the Cannon bollard is ideal for lighting projects that need high optical performance in a vandal-resistant bollard.

Request a quote

Options in this range

Name Light source
SON-T Lamp
CDO-TT Lamp
CosmoPolis Lamp

Detailed Specification

Product specification

Electrical Class:
I
IP rating:
IP55
IK rating:
IK07
Certifications:
CE
Applications:
Paths & walkways

Power and control

Voltage:
220-240V

Mechanical and installation

Materials:
Body: Cast iron
Finish:
Two-pack acrylic wet spray-paint
Product colours:
RAL 3005 Wine red
RAL 5003 Sapphire blue
RAL 6005 Light moss green
RAL 7016 Anthracite grey
RAL 7037 Dusty grey
RAL 9005 Black
Mounting:
Root mounted

Downloads and resources

Downloads

Cannon photometry

Format: ZIP compressed file, (123 KB)

Dimensions

Dimensions (mm):
  • A 1055
  • Ø B 120
  • Ø C 210
  • D 300
Weight (kg):
66
