Technical projector
Adjustable surface-mounted technical projectors. New large premium projector, extending the family with stylish modern design, unique rotary thermal guard and up to 3,600 delivered lumens.
- Die-cast aluminium housing pre-treated before powder coating ensuring high corrosion resistance
- Single cable entry
- Through wiring on request
- Stainless steel fasteners in grade 316
- Durable silicone rubber gasket
- High-efficiency optical reflector or PMMA lens
- Clear toughened glass
- Integral control gear
Detailed Specification
Product specification
Electrical Class:
I
IP rating:
IP66
IK rating:
IK08
Certifications:
CE
Applications:
Public realm
Buildings
Area lighting
Bridges & footbridges
Buildings
Area lighting
Bridges & footbridges
Lighting
Lumen Range (lumens):
2597-3634
LED qty:
3-7
Colour rendering (CRI):
>80Ra
Power and control
Voltage:
220-240V
Drive Current Range:
350mA
Mechanical and installation
Materials:
Body: Die-cast aluminium
Glazing: Glass
Glazing: Glass
Finish:
Powder coat
Product colours:
RAL 9003 White
RAL 9011 Black
RAL 6014 Bronze
RAL 7043 Dark grey
RAL 9006 Matt silver
Other RAL colours on request
RAL 9011 Black
RAL 6014 Bronze
RAL 7043 Dark grey
RAL 9006 Matt silver
Other RAL colours on request
Mounting:
Ground surface
Downloads and dimensions
Dimensions (mm):
- A 180
- B 218
- C 142
- D 308
- E 120
Weight (kg):
4.0
4.0
