Nemo 3

Change view:

Nemo 3 Product slider Product image LIGMAN 2000x1572px

Downloads

Nemo family datasheet

Format: Adobe Acrobat PDF file, (986 KB)

Nemo 3 datasheet

Format: Adobe Acrobat PDF file, (833 KB)

Nemo installation instructions

Format: Adobe Acrobat PDF file, (223 KB)

Underwater projectors

Powerful professional underwater adjustable projector family. Offering solutions for even the largest of water features.

  • Stainless steel body and fasteners in grade 316
  • Single cable entry
  • Durable silicone rubber gasket
  • High-efficiency optical reflector
  • Clear toughened glass
  • Maximum depth 2 meters
  • Luminaire must be submerged when operational
  • Accessory must be ordered separately
  • Remote driver is included
  • Remote IP box is not included
  • Outdoor cable needs to be ordered with a specific length



Request a quote

Detailed Specification

Product specification

Electrical Class:
III
IP rating:
IP68
IK rating:
IK07
Certifications:
CE

Lighting

Light source:
Chip on Board LED (CoB)
Lumen Range (lumens):
2186-2937
Power Range:
27
LED qty:
1
Distribution:
Narrow 22°
Medium 35°
Wide 52°
Asymmetric 46° x 56°
Colour Temperature (CCT):
3000K
4000K
Colour rendering (CRI):
>80Ra
Max efficacy (luminaire lumens):
up to 109lm/W
L90 Lifetime Estimate:
>50,000hrs

Power and control

Voltage:
220-240V
Drive Current Range:
700mA
Dimming:
On/Off, 1-10V, DALI
Driver included:
Remote driver included (IP65 box ordered separately)

Mechanical and installation

Tilt / inclination:
-30° to +90°
Materials:
Body: Grade 316 Stainless steel
Glazing: Glass
Product colours:
Stainless steel
Mounting:
Underwater surface

Downloads and dimensions

Nemo family datasheet

Format: Adobe Acrobat PDF file, (986 KB)

Nemo 3 datasheet

Format: Adobe Acrobat PDF file, (833 KB)

Nemo installation instructions

Format: Adobe Acrobat PDF file, (223 KB)

Completed Nemo 3 Product variant dimensions drawing LIGMAN W573px
Dimensions (mm):
  • A 140
  • B 169
  • C 60
Weight (kg):
2.9
