Nemo

Change view:

Nemo 2 Product slider Product image LIGMAN 2000x1572px

Downloads

Nemo family datasheet

Format: Adobe Acrobat PDF file, (986 KB)

Underwater projectors

Powerful professional underwater adjustable projector family. Offering solutions for even the largest of water features.

  • Stainless steel body and fasteners in grade 316
  • Single cable entry
  • Durable silicone rubber gasket
  • High-efficiency optical reflector
  • Clear toughened glass
  • Maximum depth 2 meters
  • Luminaire must be submerged when operational
  • Accessory must be ordered separately
  • Remote driver is included
  • Remote IP box is not included
  • Outdoor cable needs to be ordered with a specificĀ length

Products in this range

(3 in total)

Change view:

Contact us about this product

Detailed Specification

Product specification

Electrical Class:
III
IP rating:
IP68
IK rating:
IK07
Certifications:
CE

Lighting

Light source:
Chip on Board LED (CoB)
Lumen Range (lumens):
1173-2937
LED qty:
1
Colour Temperature (CCT):
3000K
4000K
Colour rendering (CRI):
>80Ra

Power and control

Voltage:
220-240V
Dimming:
On/Off, 1-10V, DALI
Driver included:
Remote driver included (IP65 box ordered separately)

Mechanical and installation

Tilt / inclination:
-30° to +90°
Materials:
Body: Grade 316 Stainless steel
Glazing: Glass
Product colours:
Stainless steel
Mounting:
Underwater surface

Downloads and dimensions

Nemo family datasheet

Format: Adobe Acrobat PDF file, (986 KB)

Completed Nemo 1 Product variant dimensions drawing LIGMAN W573px
Dimensions (mm):
  • A 69
  • B 89
  • C 43
Weight (kg):
0.8
Completed Nemo 2 Product variant dimensions drawing LIGMAN W573px2
Dimensions (mm):
  • A 100
  • B 122
  • C 54
Weight (kg):
1.6
Completed Nemo 3 Product variant dimensions drawing LIGMAN W573px2
Dimensions (mm):
  • A 140
  • B 169
  • C 60
Weight (kg):
2.9
