Monaro

Change view:

Monaro Street Lighting Location image 1920x1080px Alt3
Monaro Street Lighting Location image 1920x1080px Alt2
Monaro Street Lighting Product image 2000x1572px

Downloads

Monaro photometry

Format: ZIP compressed file, (825 KB)

More views

Monaro Street Lighting Product image 2000x1572px
Monaro Street Lighting Product image 2000x1572px Alt2

One of our most robust luminaires

Monaro is a modern, compact low profile luminaire. Constructed to withstand high-impact but designed to look good, this luminaire provides a smart lighting solution for residential, amenity and parking areas.

  • Recommended for mounting at 4-6 metres
  • Available with a range of lamp and LED light sources

Request a quote

Options in this range

Name Light source Distribution Power Range
Performance LED High power LED Diamond+
CosmoPolis Lamp Diamond Optic® 45, 60, 90, 140
SON-T Lamp Diamond Optic® 50, 70, 100, 150
CDO-TT Lamp Diamond Optic® 50, 70, 100, 150

Detailed Specification

Product specification

Electrical Class:
I (II on request)
IP rating:
IP66
IK rating:
IK09
Certifications:
CE
Mounting Height (m):
4-6
Applications:
Public realm
Buildings
Car parks
Rail

Power and control

Controls:
Remote switch
Remote dim
Pre-programmed dim
Photocell switch
Photocell dim
Full CMS

Mechanical and installation

Materials:
Body & Latch: High pressure die-cast aluminium
Seals: Silicone
Finish:
Polyester powder coat
Product colours:
RAL 9016 White
RAL 9005 Black
RAL 7016 Anthracite grey
RAL 7037 Dusty grey
PAN 7621 Metallic silver
RAL 9006 Aluminium
RAL 9007 Metallic grey
DB 703 Metallic dark grey
Other RAL colours on request
Mounting:
Side Entry: Ø42mm
Direct Post: Ø60mm / Ø76mm

Downloads and dimensions

Monaro photometry

Format: ZIP compressed file, (825 KB)

Monaro LED product dimension drawing W573px
Dimensions (mm):
  • A 610
  • B 330
  • C 180
Weight (kg):
13
Windage (m2):
0.09
