Mask 1

Change view:

Mask In ground Location image LIGMAN 1920x1080px2
Mask 1 Product slider Product image LIGMAN 2000x1572px

Downloads

Mask family datasheet

Format: Adobe Acrobat PDF file, (1.7 MB)

Mask 1 datasheet

Format: Adobe Acrobat PDF file, (1.1 MB)

Mask installation instructions

Format: Adobe Acrobat PDF file, (408 KB)

In-ground luminaires

Walk & drive-over semi-recessed in-ground marker lights. Tough, clean-aesthetics, with multiple light-emission directions.

  • Die-cast aluminium housing and frame pre-treated before powder coating ensuring high corrosion resistance
  • Single cable entry
  • Through wiring on request
  • Stainless steel fasteners in grade 316
  • Durable silicone rubber gasket
  • Clear glass lens
  • Integral control gear
  • Recessing box in high density polyethylene is included
  • To ensure efficient drainage, gravel must be used to a depth of 450 mm and width of 300 mm beneath the housing and should also be placed around luminaire
  • Suitable for drive-over with a maximum load of 4,000kg for fixtures ref: MK-60249 & MK-60259, 2,000kg for MK-60269 and 1,000kg for MK-60729
  • Vehicles with pneumatic tires can drive over the luminaire but the speed must not exceed 10 km/h
  • Load is transferred by the housing to the foundation



Request a quote

Detailed Specification

Product specification

Electrical Class:
I
IP rating:
IP67
IK rating:
IK10
Certifications:
CE
Applications:
Paths & walkways
Car parks

Lighting

Light source:
Chip on Board LED (CoB)
Lumen Range (lumens):
104-112
Power Range:
4
LED qty:
1
Distribution:
90°
Colour Temperature (CCT):
3000K
4000K
Colour rendering (CRI):
>80Ra
Max efficacy (luminaire lumens):
up to 28lm/W
L90 Lifetime Estimate:
>50,000hrs

Power and control

Voltage:
220-240V
Drive Current Range:
350mA
Dimming:
On/Off, 1-10V, DALI

Mechanical and installation

Materials:
Body: Die-cast aluminium
Finish:
Powder coat
Product colours:
RAL 9003 White
RAL 9011 Black
RAL 6014 Bronze
RAL 7043 Dark grey
RAL 9006 Matt silver
Other RAL colours on request
Mounting:
Ground recessed

Downloads and dimensions

Mask family datasheet

Format: Adobe Acrobat PDF file, (1.7 MB)

Mask 1 datasheet

Format: Adobe Acrobat PDF file, (1.1 MB)

Mask installation instructions

Format: Adobe Acrobat PDF file, (408 KB)

Completed Mask 1 Product variant dimensions drawing LIGMAN W573px2
Dimensions (mm):
  • A 218
Weight (kg):
4.4
