Manhattan

Change view:

Manhattan Decorative Street Lighting Location image 1920x1080px Alt2
Manhattan Decorative Street Lighting Product image 2000x1572px

Downloads

Manhattan photometry

Format: ZIP compressed file, (2.2 MB)

Manhattan product codes

Format: Adobe Acrobat PDF file, (33 KB)

A classic post-top luminaire

Manhattan's creative styling has a modern and sleek, architectural design. Paired with high performance and compatible with leading CMS, this classic post top luminaire enhances pedestrian areas, leisure parks or business developments.

  • For mounting at 4-6 metres
  • From 1300 to 4670lm
  • Base has external connector block for ease of maintenance

Request a quote

Options in this range

Name Light source Distribution Lumen Range (lumens) Power Range Colour Temperature (CCT)
Performance LED High power LED Diamond+ 1309-4673 12-47 2700K, 3000K, 4000K
CosmoPolis Lamp Diamond Optic® 45, 60, 90, 140
SON-T Lamp Diamond Optic® 50, 70, 100, 150
CDO-TT Lamp Diamond Optic® 50, 70, 100, 150

Standard colours

RAL 9016 White colour swatch 548x548px

RAL 9016

White

RAL 9005 Fine textured black colour swatch 548x548px

RAL 9005

Black

RAL 7016 Anthracite grey colour swatch 548x548px

RAL 7016

Anthracite grey

RAL 7037 Dusty grey colour swatch 548x548px

RAL 7037

Dusty grey

PAN 7621 Metallic silver colour swatch 548x548px

PAN 7621

Metallic silver

RAL 9006 Textured aluminium colour swatch 548x548px

RAL 9006

Aluminium

RAL 9007 Textured metallic grey colour swatch 548x548px

RAL 9007

Metallic grey

DB 703 Textured metallic dark grey colour swatch 548x548px

DB 703

Metallic dark grey

To personalise your scheme, other RAL colours available on request.

Detailed Specification

Product specification

Electrical Class:
I (II on request)
IP rating:
IP65
IK rating:
IK08
Certifications:
CE
Mounting Height (m):
4-6
Applications:
Public realm
High street & road lighting
Car parks
Buildings

Lighting

Lumen Range (lumens):
1309-4673
LED qty:
16-32

Power and control

Controls:
Miniature photocell
Part night switching
Pre-programmed dimming
CMS compatible
Sensor ready

Mechanical and installation

Materials:
Canopy & Brim: Spun aluminium
Base: Cast aluminium
Seals: Neoprene
Finish:
Polyester powder coat
Product colours:
RAL 9016 White
RAL 9005 Black
RAL 7016 Anthracite grey
RAL 7037 Dusty grey
PAN 7621 Metallic silver
RAL 9006 Aluminium
RAL 9007 Metallic grey
DB 703 Metallic dark grey
Other RAL colours on request
Mounting:
Ø76mm Post top

Downloads and dimensions

Manhattan photometry

Format: ZIP compressed file, (2.2 MB)

Manhattan product codes

Format: Adobe Acrobat PDF file, (33 KB)

Manhattan product dimension drawing W573px
Dimensions (mm):
  • A 810
  • Ø B 800
  • Ø C 76
Weight (kg):
18
Windage (m2):
0.19
