In-ground luminaire
Efficient quality linear fixture portfolio. Coordinated in-ground range with multiple optics and component options.
- Die-cast aluminium end-caps and extruded aluminium housing pre-treated before powder coating ensuring high corrosion resistance
- Stainless steel frame
- Single cable entry
- Through wiring on request
- Stainless steel fasteners in grade 316
- Durable silicone rubber gasket
- Clear toughened 8 mm thick glass
- Integral control gear
- Recessing box is not included
- Suitable for walk-over with a maximum load of 500kg
Detailed Specification
Product specification
Electrical Class:
I
IP rating:
IP67
IK rating:
IK10
Certifications:
CE
Applications:
Public realm
Paths & walkways
Paths & walkways
Lighting
Light source:
Surface Mounted Device LED (SMD)
Lumen Range (lumens):
1943-5703
Power Range:
28-57
LED qty:
18-36
Distribution:
Very narrow 12°
Narrow 14°
Medium 24°
Wide 44°
Elliptical 18° x 35°
Asymmetric 27° x 60°
Narrow 14°
Medium 24°
Wide 44°
Elliptical 18° x 35°
Asymmetric 27° x 60°
Colour Temperature (CCT):
3000K
4000K
4000K
Colour rendering (CRI):
>80Ra
Max efficacy (luminaire lumens):
up to 102lm/W
L90 Lifetime Estimate:
>100,000hrs
Power and control
Voltage:
220-240V
Drive Current Range:
500mA
Dimming:
On/Off, 1-10V, DALI
Mechanical and installation
Materials:
Body: Die-cast aluminium
Frame: Stainless steel
Glazing: Glass
Frame: Stainless steel
Glazing: Glass
Finish:
Powder coat
Product colours:
Stainless steel
Mounting:
Ground recessed
Downloads and dimensions
Lightalk family datasheet
Format: Adobe Acrobat PDF file, (1.1 MB)
Lightalk 1 655mm asymmetric datasheet
Format: Adobe Acrobat PDF file, (368 KB)
Lightalk 1 655mm datasheet
Format: Adobe Acrobat PDF file, (378 KB)
Lightalk 1 1250mm asymmetric datasheet
Format: Adobe Acrobat PDF file, (379 KB)
Lightalk 1 1250mm datasheet
Format: Adobe Acrobat PDF file, (385 KB)
Lightalk 1 installation instructions
Format: Adobe Acrobat PDF file, (949 KB)

Dimensions (mm):
- A 655
- B 85
- C 400
- D 85
- E 101
Weight (kg):
4.6
4.6

Dimensions (mm):
- A 1250
- B 85
- C 485
- D 85
- E 101
Weight (kg):
7.8
7.8
