Glare free, high performance asymmetric floodlighting

Kaskara is our unique LED, energy efficient floodlighting solution. Its indirect reflectors provide low glare, no upward light and a well defined rear cut-off. Providing flexible, professional and highly efficient thermal management.

  • Energy savings, up to 66% achievable
  • Choice of control options for further energy savings
  • High efficacy, up to 128lm/W

Request a quote

Options in this range

Name Mounting Height (m) Lumen Range (lumens) Power Range LED qty
Kaskara 2 6, 8, 10 10360-12693 81-108 2
Kaskara 3 8, 10, 12 15540-19040 121-161 3

Design features




Standard colours

RAL 9016 White colour swatch 548x548px

RAL 9016

White

RAL 7035 Light grey colour swatch 548x548px

RAL 7035

Light grey

RAL 7046 Textured grey colour swatch 548x548px

RAL 7046

Mid grey

RAL 9005 Fine textured black colour swatch 548x548px

RAL 9005

Black

To personalise your scheme, other RAL colours available on request.

Detailed Specification

Product specification

Electrical Class:
I
IP rating:
IP66
IK rating:
IK08
Certifications:
CE
Mounting Height (m):
6-12
Applications:
Car parks
Buildings
Rail
Area lighting

Lighting

Light source:
Chip on Board (CoB)
Lumen Range (lumens):
10360-19040
LED qty:
2-3
Distribution:
Narrow Beam
Wide Beam
Colour Temperature (CCT):
3000K
4000K
4000K SUNLIKE
Colour rendering (CRI):
70Ra
Max efficacy (luminaire lumens):
128lm/W
L80 Lifetime Estimate:
>100,000hrs

Power and control

Voltage:
220-240V
Drive Current Range:
700mA
1000mA
Controls:
Miniature photocell
Part night switching
Pre-programmed dimming
NEMA photocell
Integral CMS
Surge protection:
10kV
Driver:
Philips Xi

Mechanical and installation

Materials:
Body: Aluminium
Seals: Silicone rubber
Glazing: Toughened glass
Finish:
Textured polyester powder coat
Product colours:
RAL 9016 White
RAL 7035 Light grey
RAL 7046 Mid grey
RAL 9005 Black
Other RAL colours on request
Operating temp (°C):
-25°C to +30°C
Mounting:
Stirrup Bracket
Post Top
Linear Bracket

Downloads and resources

Downloads

Kaskara brochure

Format: Adobe Acrobat PDF file, (1.9 MB)

Kaskara photometry

Format: ZIP compressed file, (78 KB)

Kaskara product codes

Format: Adobe Acrobat PDF file, (45 KB)

Dimensions

Kaskara product dimension drawing W573px
Dimensions (mm):
  • A 585
  • B 220
  • C 500
Weight (kg):
12.6
Windage (m2):
0.08
