Peak 380

Change view:

Peak 380 Decorative Street Lighting Location image 1920x1080px
Peak 380 Focus Lighting Product image 2000x1572px

Downloads

Focus Lighting brochure

Format: Adobe Acrobat PDF file, (7.9 MB)

Peak brochure

Format: Adobe Acrobat PDF file, (5.6 MB)

Peak 380 photometry

Format: ZIP compressed file, (351 KB)

More views

Peak 380 Focus Lighting Product image 2000x1572px
Peak 380 Decorative Street Lighting Product image 2000x1572px

Contemporary, low-profile luminaire, from Focus by DW Windsor

Peak 380, designed by AART designers, offers flexible, efficient lighting performance and striking contemporary Danish design, it's characterised by functionality, simplicity and strong lines. With separate side entry and direct post mounting options available to avoid compromising design.

  • Recommended for mounting at 4-10 metres
  • Available in 1, 2 or 3 LED modules
  • 3000K and 4000K CCT options available

Request a quote

Product Selector

Mounting Height (m)4-10

Lumen Range (lumens)up to 12000-up to 8000

Options in this range

Name Mounting Height (m) Lumen Range (lumens) Power Range LED qty
1 LED module 4-6 up to 4200 up to 40 16
2 LED modules 6-8 up to 8000 up to 75 32
3 LED modules 8-10 up to 12000 up to 114 48

Detailed Specification

Product specification

Electrical Class:
I (II on request)
IP rating:
IP66
IK rating:
IK09
Certifications:
CE
Mounting Height (m):
4-10
Applications:
Public realm
High street & road lighting
Car parks
Buildings

Lighting

Light source:
Philips Fastflex
Lumen Range (lumens):
up to 12000-up to 8000
LED qty:
16-48
Distribution:
Residential
Road
C Class
Pedestrian Crossing
Colour Temperature (CCT):
3000K
4000K
Colour rendering (CRI):
70Ra (typically 75Ra)
80Ra (on request)
L80 Lifetime Estimate:
>100,000hrs

Power and control

Voltage:
220-240V
Dimming:
1-10V, DALI
Surge protection:
L/N-GND: 8kV
L-N: 6kV
Driver:
Philips Xi FP

Mechanical and installation

Materials:
Body: High pressure die-cast aluminium
Glazing: 3mm toughened glass
Seals: Silicone
Finish:
Polyester powder coat
Product colours:
SW302G Graphite grey (close to RAL 9007)
MW300D Silver grey
SN351F Black (Noir 900 Sablé)
Other RAL colours on request
Operating temp (°C):
-30°C to +35°C
Mounting:
Side Entry: Ø42mm / Ø48mm / Ø60mm
Direct Post: Ø60mm / Ø76mm

Downloads and dimensions

Focus Lighting brochure

Format: Adobe Acrobat PDF file, (7.9 MB)

Peak brochure

Format: Adobe Acrobat PDF file, (5.6 MB)

Peak 380 photometry

Format: ZIP compressed file, (351 KB)

Peak 380 installation instructions

Format: Adobe Acrobat PDF file, (229 KB)

Peak 380 Direct Post product dimension drawing W573px
Dimensions (mm):
  • A 114
  • B 380
  • C 498
Weight (kg):
6-7
Windage (m2):
0.05
Peak 380 Side Entry product dimension drawing W573px
Dimensions (mm):
  • A 114
  • B 380
  • C 490
Weight (kg):
6-7
Windage (m2):
0.05
