Minimalist Scandinavian bollard, from Focus by DW Windsor

The Nyx 190 Bollard luminaire, designed by Vilhelm Lauritzen Architects, is characterised by pleasant, indirect light with low glare. As part of the Nyx family, Nyx 190 Bollard can be combined with matching column and wall mounted luminaires for a consistent aesthetic across a scheme.

  • Diffused glazing for comfortable, pedestrian-friendly lighting
  • 2700K, 3000K and 4000K CCT options available

Request a quote

Detailed Specification

Product specification

Electrical Class:
I (II on request)
IP rating:
IP66
IK rating:
IK10
Certifications:
CE
Applications:
Public realm
Paths & walkways

Lighting

Light source:
2 x Bridgelux V6
Lumen Range (lumens):
570-740
Power Range:
9-16
LED qty:
2
Distribution:
Asymmetric
Colour Temperature (CCT):
2700K
3000K
4000K
Colour rendering (CRI):
>90Ra (2700K / 3000K)
>80Ra (4000K)
Max efficacy (luminaire lumens):
80lm/W
L80 Lifetime Estimate:
>100,000hrs

Power and control

Drive Current Range:
350mA
500mA
Controls:
Remote switch
Driver:
Helvar

Mechanical and installation

Materials:
Body: Aluminium
Glazing: Frosted polycarbonate
Seals: Silicone
Finish:
Polyester powder coat
Product colours:
SW302G Graphite grey
MW300D Silver grey
SN351F Black (Noir 900 Sablé)
RAL 9005 Black
YX355F Corten brown (Mars 2525)
Other RAL colours on request
Mounting:
Root mounted
Flange plate

Downloads and dimensions

Focus Lighting brochure

Format: Adobe Acrobat PDF file, (7.9 MB)

Nyx brochure

Format: Adobe Acrobat PDF file, (4.2 MB)

Nyx 190 Bollard photometry

Format: ZIP compressed file, (26 KB)

Nyx 190 Bollard installation instructions

Format: Adobe Acrobat PDF file, (576 KB)

Nyx 190 Bollard product dimension drawing W573px
Dimensions (mm):
  • A 1000
  • B 120
  • C 40
  • D 190
  • E 190
Weight (kg):
5-6

The Nyx range
