Fira Pro Max

Change view:

Fira Pro Max Projector Product image 2000x1572px

Downloads

Fira Pro brochure

Format: Adobe Acrobat PDF file, (1.6 MB)

Fira Pro photometry

Format: ZIP compressed file, (42 KB)

Detailed Specification

Product specification

Electrical Class:
I
IP rating:
IP65
IK rating:
IK08
Certifications:
CE
Applications:
Buildings
Public realm

Lighting

Light source:
High power LED
Lumen Range (lumens):
1000-1200
Power Range:
12
LED qty:
8
Distribution:
Narrow Beam
Medium Beam
Wide Beam
Colour Temperature (CCT):
3000K
4000K
Colour rendering (CRI):
70Ra, 80Ra
Max efficacy (luminaire lumens):
100lm/W
L70 Lifetime Estimate:
>50,000hrs

Power and control

Voltage:
220-240V

Mechanical and installation

Materials:
Body: High pressure die-cast aluminium
Glazing: Flat toughened glass
Finish:
Fine texture polyester powder coat
Product colours:
RAL 9006 Aluminium
Other RAL colours on request
Mounting:
Stirrup Bracket
Outreach Bracket

Downloads and resources

Downloads

Fira Pro brochure

Format: Adobe Acrobat PDF file, (1.6 MB)

Fira Pro photometry

Format: ZIP compressed file, (42 KB)

Dimensions

Fira Pro Max product dimension drawing W573px
Dimensions (mm):
  • A 378
  • B 244
  • C 128
Weight (kg):
5
