Vandal resistant, entry-level luminaire

Constructed to withstand vandalism and to offer uncompromising performance, DW400 is a robust and practical range perfectly suited for vulnerable residential areas.

  • Suitable for mounting at 4-6 metres
  • Exceptional ease of maintenance via stainless steel over-centre latches

Request a quote

Options in this range

Name Light source Lumen Range (lumens) Power Range LED qty Colour Temperature (CCT)
Performance LED High power LED 2872-9330 22-77 16, 32 2700K, 3000K, 4000K
SON-T Lamp 50, 70, 100
CDO-TT Lamp 50, 70, 100
Cosmopolis Lamp 45, 60, 90

Glazing options


DW400 is available with two different glazing options.

Standard colours

RAL 9005 Fine textured black colour swatch 548x548px

RAL 9005

Black

RAL 7016 Anthracite grey colour swatch 548x548px

RAL 7016

Anthracite grey

RAL 7037 Dusty grey colour swatch 548x548px

RAL 7037

Dusty grey

RAL 5003 Sapphire blue colour swatch 548x548px

RAL 5003

Sapphire blue

RAL 6005 Light moss green colour swatch 548x548px

RAL 6005

Light moss green

To personalise your scheme, other RAL colours available on request.

Detailed Specification

Product specification

Electrical Class:
I
IP rating:
IP66
IK rating:
IK07
Certifications:
CE
Mounting Height (m):
4-6
Applications:
High street & road lighting
Rail
Car parks

Lighting

Lumen Range (lumens):
2872-9330
LED qty:
16-32

Power and control

Voltage:
220-240V
Controls:
Miniature photocell
Part night switching
Pre-programmed dimming
NEMA photocell
CMS compatible
Sensor ready

Mechanical and installation

Materials:
Body: High pressure die-cast aluminium
Canopy: Spun aluminium
Seals: Silicone
Glazing: Flat toughened glass or Polycarbonate bowl
Finish:
Polyester powder coat
Product colours:
RAL 9005 Black
RAL 7016 Anthracite grey
RAL 7037 Dusty grey
RAL 5003 Sapphire blue
RAL 6005 Light moss green
Other RAL colours on request
Mounting:
Side Entry: Ø42mm / Ø60mm
Direct Post: Ø60mm / Ø76mm

Downloads and resources

Downloads

Retrofit LED Solutions brochure

Format: Adobe Acrobat PDF file, (1.8 MB)

Light Engine design guide

Format: Adobe Acrobat PDF file, (6.6 MB)

DW400 photometry

Format: ZIP compressed file, (6.6 MB)

DW400 product codes

Format: Adobe Acrobat PDF file, (39 KB)

Dimensions

DW400 product dimension drawing W573px2
Dimensions (mm):
  • A 265
  • Ø B 450
Weight (kg):
9.8
Windage (m2):
0.09
DW400 product dimension drawing W573px2
Dimensions (mm):
  • A 192
  • Ø B 450
Weight (kg):
10.4
Windage (m2):
0.07
